Multi Rip Saw

Product Model：

SM4305

Professional solution for the multi-slicing and fixed-width longitudinal cutting, suitable for the wood block with thickness not more than 85mm, width not more than 300mm, and length not less than 350mm.

Inquiry

E-mail：jangja@jangja.com

Detailed Description
Technical Specifications

Standard


Multi anti-kickback fingers to prevent wood chips from rebounding.	Saw spindle limit switch.	Pressure mechanism limit switches & locking device, avoid machine damage due to the false operation.

Optional


Laser marker predicts the cutting route and improves the utilization rate of the wood.(except AM4500).	Worktable built-in roller.	According to the actual requirements, choose the saw blade with different diameters that will influence the saw spindle speed.

SM4305 optional nail chain plate, precise positioning of wood, precise sawing.	Automatic material handling device.	Feed in and out auxiliary bracket.

Saw blade cooling and lubrication device can cool and lubricate the saw blade at any time according to the state of the machine, improve the sawing precision and extend the service life of the saw blade.

Item	Machine model
	SM4305
	Technical data
Working thickness	10-70mm (range10-85mm)
Working thickness when with pressure board	10-70mm
Working width	3-300mm
Max. ingoing width	700mm
Min.working length	350mm
Saw blade dia	Ф205-305mm
Saw blade inner bore dia	Ф70mm
Saw spindle rotation speed	4200rpm
Saw blade cutting speed	44-66m/s
Total motor power	39.57kW
Saw spindle motor power	（22kW、30kW range） 37kW（45kW range）
Feeding motor power	2.2kW
Pressure mechanism elevation motor	0.37kW
Saw spindle elevation motor	/
Feeding speed	6-40m/min
Qty of saw blades	/
Saw spindle dia	Ф50mm
Qty of pressure rollers	6(units)
Machine size	(approx)2220×1650×1770mm
Packing size	2050×1800mm
Machine weight	(approx)2600kg
Dust exit	Ф180mm×2
Required suction speed	(approx)30-40m/s
Required suction volume	(approx)6000m³/h
Spike link chain conveyor	○
Auxiliary pressure roller at out-feed end	○
Extension table at both ends	○
Laser marker	○
Automatic material handling device	○
Automatic sprinkler system	○
Automatic water cooling device for moisturized wood processing	○
Magnetic grating digital readout	/
PLC + touch screen	/
Pneumatic feeding rollers individually adjusted	/
Chain drive, no slipping	/
